Het Binocular model van Hikmicro is niet meer verkijgbaar. Hievran komt namelijk een vernieuwd model (Hikmicro Raptor) met verbeterde aanpassing. De informatie tekst van de Raptor volgt in de komende dagen op onze website.
HIKMICRO Binocular TS16-35 Warmtebeeld & Nachtzicht (2 in 1)
Hikvision DS-2TS16-35VI/W Handheld Thermal & Optical Bi spectrum Binocular is equipped with ultra low light optical detector, 640 × 512 thermal detector, 1024×768 OLED display and eyepiece with large field of view. The device can quickly discover and locate hiding objects even und er extreme environment, such as smoke, fog, rain and snow. It can be widely applied to scenarios like patrol, law enforcement, search and rescue, drug enforcement, anti smuggling and suspect capture.
Key Features
- Thermal: 640 × 512@25fps, optical: 1280 × 960@25fps
- NETD < 40mk (@25°C,F#=1.0)
- DDE (Digital Detail Enhancement)
- 3D DNR, adaptive AGC (Automatic Gain Control)
- Ultra low illumination (optical channel), B/W: 0.001 lux @ (F1.0 , AGC On )
- 0.39 inch OLED display
- Automatic OLED backlight
- Manual focus for thermal lens
- Bi spectrum image fusion and object highlight (detail enhancement and target
- Video recording, replay, picture snapshot and search (capable to review the event on device)
- Wi Fi hot spot, GPS, cursor display
- Up to 7 hours contin uous running
- IP67
Specifications
Thermal Module
Image sensor: Uncooled Focal Plane Arrays
Max. Resolution: 640 × 512@25fps
Pixel Pitch: 17μm
Response waveband: 8μm to 14μm
NETD: < 40mk (@25°C,F#=1.0)
Lens (focal length): 35mm
MRAD (IFOV): 0.486
Field of View: 17.7° × 14.2°
Aperture: F 1.0
Digital Zoom: 4×
Optical Module
Image Sensor: 1/3” Progressive Scan CMOS
Min. Illumination: B/W : 0.001 lux @ (F1.0 , AGC On )
Max. Resolution: 1280 × 960@25fps
Lens (focal length): 12mm, Manual focus
Image Enhancement: 3D DNR, Adaptive AGC
Image Display
Monitor: 0.39-inch, OLED, 1024 ×768
Thermal/Optical Mode: Thermal view, B/W optical view, image fusion view are selectable
Image Fusion: Color fusion, B/W fusion
Palettes: Black hot, white hot
Smart
Hot Track: Yes
Object Highlight: Yes
Cursor Display: A cursor shows in the view for roughly measuring distance from the target.
Automatic Backlight: The OLED backlight automatically turns off if no human eyes are detected.
System
Storage: Built-in memory module (32GB)
Record Video: On-board video recording
Snapshot: On-board image capturing
Video Replay: Yes
Picture Search: Yes
Wi-Fi: Yes
GPS: Yes
Power Supply
Battery Type: Four 18650 batteries, requires 5 hours to be fully charged
Battery Operating Time: ≥7h
Battery Capacity Display: Yes
General
Power: 5V DC/2A
Working Temperature: -30 °C to 55 °C (-22 °F to 131 °F)
Protection level: IP67
Mounting: UNC 1/4”-20
Cable Output: Aviation plug: connecting to BNC, DB9, and USB
Accessories (Supplied): Battery charger, battery charger power cable, wiping cloth, two wrist straps, User manual, aviation plug cable, eight batteries
Dimension (L x W x H): 164mm × 182.3mm × 73.3mm (6.46" × 7.18" ×2.89")
Weight: <1.0kg (2.20 lb)
Wi-Fi Code: always the 9 last numbers and letters of the Serial number
Wide Range Coverage for Different Specifications
Note: The table below is only for reference, the performance varies from model to model, and the specific data is based on 17 μm pixel pitch.
- Lens (focal length): 35mm
- Detection range (Vehicles): 3157m
- Detection range (Humans): 1029m
- Recognition range (Vehicles): 789m
- Recognition range (Humans): 257m
- Identification range (Vehicles): 158m
- Identification range (Humans): 51m
What is in the box
- HIKMICRO Binocular TS16-35
- Battery charger
- Battery charger power cable
- Wiping cloth, two wrist straps
- User manual
- Aviation plug cable
- 8 batteries
