Pulsar Axion XQ38 LRF Warmtebeeld (met afstandmeter)

Warmtebeeld Axion XQ38 LRF (met afstandmeter)

Artikelnummer

77428

Standaard levertijd

Uit voorraad leverbaar

€ 2.349,00
€ 2.195,00
Prijs per stuk



Aantal:
Bestellen

Pulsar Axion XQ38 LRF Warmtebeeld (met afstandmeter)

The NEW LEVEL OF THERMAL SPOTTING


Built-In Precision Laser Rangefinder

Integrated, precision laser rangefinder provides accurate rangefinding in two modes – Single Time Measurement and Scanning mode with ±1 m accuracy up to 1 km distance. Accurate distance readings help to quickly assess the size of territory, distance and relief.

Highly sensitive thermal imaging sensor

The Axion XQ’s 384x288 @ 17 µm thermal imaging sensor with NETD 40mK ensures perfect detail recognition even in the hardest weather conditions when thermal contrast is low. The smallest temperature differences will be clearly visible during the rainfall, fog or cold mornings in the most difficult conditions for thermal imager.

Light-weight and Rugged Magnesium Alloy Housing

Housing made from light-weight magnesium alloy ensures high structural rigidity and ruggedness. Small weight of the monocular makes it a perfect option for long outdoor trips when light yet capable unit is necessary.

Detection range more than 1300 meters

A powerful F38/1.2 objective lens combined with a 384x288@17µm highly-sensitive thermal imaging sensor provides exceptional detection capabilities. A standard 1.8m tall object can be detected up to 1350 m away in complete darkness.

Image Boost Technology

Pulsar’s proprietary Image Boost Technology is comprised of software algorithms designed to increase imaging clarity and overall image detail. Image Boost results in a sharper, more detailed field of view and enhanced object identification capabilities.

   Image Boost OFF                                     -------               Image Boost ON


IPX7 Waterproof Rated

IPX7 waterproof-rated for protection from heavy rainfall, snow or other precipitation. The unit is designed to run flawlessly, even after submersion in up to 1 meter of water for up to 30 minutes.



More features

Full-Color, HD AMOLED Display

New HD display delivers crisp, richly contrasted, vividly colored field of view, AMOLED technology ensures flawless, fluid, high-resolution imaging and power saving.

B-Pack mini APS5 battery system

B-Pack mini APS5 battery system

Quick-change high capacity rechargeable Li-Ion battery offers 6 hours of operation time on single charge. Fast and easy battery replacement in combination with instant start-up ensure continuous observation without disruptions. Ordinary power bank connected via USB Type-C socket can be used as an external power source.

Observation Modes

Image optimization should be performed depending on the environmental location and conditions. Mountains, cities and forests have different ambient temperatures. In order to achieve the highest possible image quality, certain settings have been optimized and gathered into profiles. As a result, optimized imaging in various conditions is easier. Identification preset is another optimal-imaging option that makes identifying easier, even at longer distances.

Color Palettes

The 8-color palette enhances viewing in varying conditions. While the classic White Hot mode is exceptionally versatile, Hot Black is often favored for detecting wildlife at night. Red Monochrome helps to reduce or prevent bright backlight from exiting the eyepiece. Sepia often improves long-range observation while Red Hot, Rainbow and Ultramarine enhance temperature differences of various object attributes. Violet helps to identify objects faster.

Variable Digital Zoom from 3.5x to 14x

Digital zoom, up to 14x, provides improved focus and better overall object recognition at significant distances. The zoom changes either gradually in 2x step or continuously for a truly optimum, customized field of view for specific situation.

Picture-in-Picture Function

Picture-in-picture displays a magnified image at the top-center 10% of the overall field of view for precise zooming on an object of interest.


Specifications

Main
Sensor: 384x288 pix. @ 17 µm (NETD <40 mK)
Objective lens: F38/1.2
Magnification, x: 3.5 – 14 (x4 zoom)
Field of view (HxV), degrees / m@100m: 9.8x7.4 / 17.2x12.9
Detection range, m: 1350

Sensor
Type: uncooled
Resolution, pixels: 384x288
Pixel pitch, µm: 17
Frame rate, Hz: 50

Optics
Objective lens: F38/1.2
Magnification, x: 3.5 – 14
Field of view (HxV), degrees / m @ 100 m: 9.8x7.4 / 17.2x12.9

Display
Type: AMOLED
Resolution, pixels: 1024x768

Range Performance
Detection range, m: 1350

Video Recorder
Video / photo resolution, pixel: -
Video / photo format: -
Built-in memory, Gb: -

Environmental Characteristics
Degree of protection, IP code (IEC60529): IPХ7
Operating temperature range, °С: -25 – +40

Power Supply
Output voltage, V: 3.0 - 4.2
Battery type: Li-Ion Battery Pack APS5
Capacity, mAh: 4900
External power supply, V: 5V

Wi-Fi
Frequency, GHz: 2.4GHz
Standard: 802,11 b/g
Line-of-sight reception range, m: 15

Weight & Size
Dimensions, mm: 167x49x73
Weight, kg: 0.35

Trade Data
SKU (Model #): 77427
